220V Flat Wire Stator Rotor Winding Insertion Machine Highly Automated

Product Details:

Place of Origin:	China
Brand Name:	Champypund
Certification:	ISO9001:2015

Detail Information

Place of Origin:

China

Brand Name:

Champypund

Certification:

ISO9001:2015

Name:

Automatic Wire Insertion Machine

Durability:

High-Durability

Application Area:

Flat Wire Stator

Operation Mode:

Automation

Automation Level:

Highly Automated

Control System:

PLC Program

Customization:

Allowed

Number Of Stator Layers:

More Than 4 Layers

Aspect Ratio Of Flat Copper Wire:

Greater Than Or Equal To 1.5

Air Pressure:

(0.4-0.7)Mpa

Voltage:

220V

Power:

5kW

Warranty:

12 Months

Highlight:

High Light

Highlight:

220V rotor coil winding machine

Highly Automated rotor coil winding machine

220V bldc motor production line

Trading Information

Minimum Order Quantity:

1 SET

Price:

NEGOTIABLE

Packaging Details:

PLYWOOD CASE WITH PLASTIC BAG OR OTHER PACKAGES SUITABLE FOR SEA TRANSPORT

Delivery Time:

4-6 WEEKS

Payment Terms:

L/C,T/T

Supply Ability:

1 SET PER 4-6 WEEKS

Product Description

220V Flat Wire Stator Rotor Winding Insertion Machine

Highly Automated Motor Coil Assembly Solution

Our high-durability flat wire stator automatic wire insertion machine enhances productivity and product quality through precision engineering. Designed for accuracy, this system ensures perfect copper wire winding onto stators - critical for producing premium quality motors.

Machine Specifications

Feature	Specification
Durability	High-Durability
Application Area	Flat Wire Stator
Operation Mode	Automation
Automation Level	Highly Automated
Control System	PLC Program
Customization	Allowed
Number of Stator Layers	More Than 4 Layers
Aspect Ratio of Flat Copper Wire	≥ 1.5
Air Pressure	0.4-0.7MPa
Voltage	220V
Power	5kW
Warranty	12 Months

Technical Features

Intelligent Monitoring: Advanced sensors and control systems monitor winding insertion status in real-time with automatic process adjustment
Precision Engineering: High-precision transmission and positioning systems ensure accurate winding insertion
Adaptive Design: Accommodates various flat wire stator specifications and models
Error Prevention: Comprehensive interlocking programs, guidance mechanisms, and sensor monitoring/alarm systems
Advanced Sensing: High precision sensors and pressure parameter detection systems
Precision Control: Servo feed for exact wire insertion length control; servo module parameterized insertion depth control

Key Advantages

Adaptable control algorithms automatically adjust to different flat wire sizes and stator requirements
High-speed servo motors and precision transmissions enable rapid, accurate wire insertion
Advanced visual inspection system maintains quality standards by automatically rejecting defects
Flexible design accommodates various stator shapes, sizes, and complex winding configurations
Intelligent diagnostic system predicts potential issues, minimizing downtime

Production Line Integration

Our motor stator production line includes wire forming machines, press-in machines, widening machines, head twisting machines, flat cutting machines, and welding machines. Each machine operates independently or can be connected via conveyor belt for integrated production.

OEM/ODM Capabilities

Our professional team of engineers and technicians, equipped with advanced machinery and strict process controls, delivers optimal flat wire motor manufacturing solutions tailored to your specific requirements.

Research & Development Services

We offer comprehensive technical consultancy and turnkey project services for flat wire motor manufacturing, including motor costing analysis, manufacturing technology implementation, staff training, and complete production solutions.
